Characteristics of tin plated copper wire |
||||||||||||
Diameter /mm | Tolerance/mm | Ovality max/mm | Thickness of Coating /µm |
Elongation/% |
Tensile Strength /kg/mm2 |
Min. Bend Property /g |
Electric resistivty Ωmm2/m |
|||||
Soft |
1/2H |
H |
Soft |
1/2H |
H |
Weight |
times |
|||||
0.3 |
±0.01 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.32 |
±0.01 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.36 |
±0.01 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.38 |
±0.01 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.4 |
±0.01 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.41 |
±0.01 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.42 |
±0.01 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.43 |
±0.01 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.44 |
±0.01 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.45 |
±0.01 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.46 |
±0.01 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.47 |
±0.01 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.48 |
±0.01 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.49 |
±0.01 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.5 |
±0.01 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.52 |
±0.01 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.53 |
±0.01 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.54 |
±0.01 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.55 |
±0.015 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.56 |
±0.015 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.58 |
±0.015 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
250 |
≥5 |
≤0.0190 |
0.6 |
±0.015 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
0.62 |
±0.015 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
0.65 |
±0.015 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
0.66 |
±0.015 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
0.68 |
±0.015 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
0.7 |
±0.015 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
0.72 |
±0.015 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
0.74 |
±0.015 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
0.75 |
±0.015 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
0.76 |
±0.015 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
0.78 |
±0.015 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
0.79 |
±0.015 |
0.01 |
5±2 |
≥20 |
13~23 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
0.8 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
0.81 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
0.82 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
0.85 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
0.9 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
0.95 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
0.98 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.02 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.03 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.05 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.1 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.13 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.15 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.2 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.25 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.3 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.35 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.38 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.4 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.45 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.5 |
±0.015 |
0.01 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.6 |
±0.02 |
0.015 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.62 |
±0.02 |
0.015 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.65 |
±0.02 |
0.015 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.7 |
±0.02 |
0.015 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.71 |
±0.02 |
0.015 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
1.8 |
±0.02 |
0.015 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
2 |
±0.02 |
0.015 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
2.13 |
±0.02 |
0.015 |
5±2 |
≥25 |
13~24 |
≤12 |
20~28 |
20~28 |
≥40 |
500 |
≥6 |
≤0.0182 |
